JA Solar JAM78S30MR

580W 585W 590W 595W 600W 605W JA Deepblue 3.0 Series Half Cell Module, with higher power generation better LCOE, better temperature coefficient, lower LID and better low irradiance response.

86 18961863192

sean@guanjisolar.com

Product Description

MECHANICAL DATA
Cell	Mono
Weight	30.5kg
Dimensions	2465±2mm1134±2mm35±1mm
Cable Cross Section Size	4mm²(IEC)，12 AWG(UL)
No. of cells	156(6*26)
J-Box	IP68, 3 diodes
Connector	QC 4.10-351/ MC4-EVO2A

ELECTRICAL DATE(STC)
Rated Maximum Power(Pmax)[W]	580	585	590	595	600	605
Power Tolerance	0~+5W
Open Circuit Voltage(Voc) [V]	53.11	53.2	53.3	53.4	53.5	53.61
Maximum Power Voltage(Vmp) [V]	44.35	44.56	44.8	45.05	45.3	45.53
Short Circuit Current(lsc) [A]	13.84	13.88	13.93	13.98	14.03	14.08
Maximum Power Current(lmp) [A]	13.08	13.13	13.17	13.21	13.25	13.29
Module Efficiency[%]	20.70%	20.90%	21.10%	21.30%	21.50%	21.60%
